When doing some project which involves a microcontroller I often have to write some test code/script in order to verify correct operation. This is typically a time consuming process. So some time ago, I started working on a small side-project, which would allow me to communicate with a microcontroller directly, either via UART-USB bridge or some other transport protocol. The idea was to basically recreate a unix like shell, where I could control peripherals, via short commands and maybe do some scripting as well and the whole project should be easy to expand and maintain.

Sources are available here.

Syntaxis

The syntaxis I landed on is pretty simple, just a command name followed by a space and optional arguments. Arguments are always separated by a dash.  Nothing more to say here.

Modules

Modules are made of a primary function which is called when command is executed and is responsible for handling argument parsing and error checking. There are several modules I've written sofar:

Exit Module

Actually does very little, takes no arguments. Waits a couple of seconds and causes uC to restart itself. Not particularly useful.

ADC Module

As expected, controls an onboard 12 bit ADC. Features:

  • Single/All channel(s) read.
  • Individual comparator/trigger on all channels
  • Can write data to pool module

Example:

adc -c -0  		// enable trigger on adc channel 0
adc -t -0 -7  	// set trigger voltage to 0.7 Volts
adc -s -5 		// set timeout to 5 seconds and wait for trigger

UART Module

Actually, just a placeholder for now, haven't started on this one yet.

GPIO Module

Can control any port, with two access methods, pin mode and port mode (individual setting for each port).

  • Read/Write operations (including to pool module)
  • Individual port/pin mode access, individual pull-up assignments.

Example:

gpio -b -h  	// read port B and return port value as hex (value will be written to pool variable)
gpio -b -g 		// read port B and return value as binary
gpio -b -5 -5 	// will set port B to 0x55
gpio -b -p 		// switch to pin mode
gpio -b -4 -1 	// set pin 4 high at port B

Help Module

Executing "help -h" will display all modules with short descriptions

Time Module

Generic timekeeping functionality, showing uptime and usage statistics

  • Keeps track of uptime down to 1/10 of a second
  • Can cause delay during script execution with either second/millisecond accurancy

Example:

time -m -1 // causes a 100 ms delay

Print Module

Generic debug module, shows various info.

  • Display current/previous command information (command code, id, arguments etc.)
  • Display uart stats
  • Display script/stack stats.

Stat Module

Microcontroller stats such as speed, flash and sram size. System interrupts status.

Queue Module

Scripting module used to record executed commands and run them in a loop or from-to specific positions

Example (Blink a Led):

gpio -b -p    	// set port B to pin mode
queue -s  		// enable scripting module
gpio - b -0 -1 	// set pin 0 on port B to logic high
time -m -1 		// delay for 100 ms
gpio -b -0 -0 	// set pin on port B to logic low
queue -f 		// enable continious script execution

Map Module

Not sure why I wanted this module :)

Clear Module

Clears the screen when called. Works with PuTTY, should work with other terminals as well.

Pool Module

Contains 8 individual variables, where each variable has a history property which stores up to 7 previous values.

  • Allmost any IO module can read/write to from pool variables
  • Individual write access
  • Increment/Decrement, Left/Right shift, Accumulate, Randomize, Bargraph functions

Example:

pool -s -0 		// select variable at location 0
pool -i -8 		// increment variable by 0x8
pool -c -3 		// copy variable from current location to location 3
pool -s -3 		// select variable 3
pool -f 		// convert variable at location 3 to unfilled bargraph value
gpio -b -p    	// select port mode on port B
gpio -b -v 		// write current pool value (at location 3)  to gpio port B

Jump Module

This module can only be used within the scripting mode for conditional jumping.

  • Branches on equal/nequal/larger/smaller

Example (Counter):

pool -Z 		// delete all pool variables
pool -s -0 		// select variable 0
queue -s 		// enable scripting mode
pool -i -1 		// increment variable by one
jump -i -0 -1 	// set jumping index to 1
jump -v -0 -8 	// set jumping value to 8
jump -l 		// Jump to index 1, if value has not reached 8
queue -b 		// counter has reached 8, cancel script execution

Proc Module

Controls functions which are compiled together with the firmware and registered in proc module.

  • Single/Continuous process execution
  • Process scheduler with sequential/random patterns
